Albumen-coated paper trial print for the heliogravures of the Duc de Luynes, Voyage D’Exploration a La Mer Morte from the family archive and Charles Nègre’s personal album. A number of prints feature clouds drawn over neutral skies; hand-drawn by Nègre. These appear mostly on reverse prints and correspond to the clouds that are featured in the gravures of the Atlas. They serve for markers and memory aids for Nègre’s hand drawings on the heliographic steel plates.  While the sky conveys a graphic handling supplied by the hand of the artist; the one is photographic and reproduced without the hand, the other is graphic and completed by the hand. These two divergent aims form the central formal tension in Nègre’s photogravures. For the photogravures, Nègre created cloud formations through a combination of acid- resistant varnish brushed on to the plate, powdered resin distributed over the plate’s surface, and successive submersions of the plate in an acid bath. The final results demonstrate Nègre’s technical and visual sophistication with platemaking.  As seen here, Négre also often added diminishing layers of horizon manually in the photogravures adding depth and atmosphere to the images.
In 1856, Honoré d’Albert, Duc de Luynes, archaeologist, scientist and connoisseur, initiated a competition in conjunction with the Société Française de Photographie (SFP) to find the best method of photomechanical reproduction. The major prize of 7,000 francs was awarded 11 years later to Alphonse Louis Poitevin for his method of photolithography. Poitevin’s method had been shortlisted for the award 1856, but declaring a winner was delayed for years because the judges considered none of the processes entered to be perfect and postponed their decision until it was clear that nothing better was imminent. Poitevin became victor by default.
Meanwhile, the competition’s instigator, the Duc de Luynes, had led a geological expedition to the Dead Sea in 1864 and, upon his return, proposed to publish the pictures taken by the party’s photographer, Louis Vignes. But rather than choosing the winner of his competition to make the photomechanical reproductions, the Duc selected Charles Nègre, who had also been shortlisted for the prize. Nègre had developed a photogravure method that produced beautiful prints but was even more complicated and unwieldy in practice than Poitevin’s method- an impediment that clashed with the competition’s aim of finding the most practicable system.
Albumen prints made from Vignes’ original negatives from the expedition show the myriad of flaws that Luynes had to overcome. They were taken in harsh conditions – poorly exposed and flawed. Overcoming these issues, Nègre was able to open up the shadows and fill them with light, detail and space. “Undoubtedly the main reason the Duke chose Nègre to perform this task lay in the quality of the prints Nègre was capable of producing … for he had achieved a control over his process which resulted in prints of rich tones, fine detail, transparency and effect" . For the photogravures, Nègre created cloud formations through a combination of acid resistant varnish brushed on to the plate, powdered resin distributed over the plate’s surface, and successive submersions of the plate in an acid bath. The final results demonstrate Nègre’s technical and visual sophistication with platemaking. Not only was Nègre capable of mending Vignes’ negatives, His photogravures transformed the photographs into evocative images of great poetry ‘Ultimately foiled by his own artistry, Nègre was not awarded the Duke de Luynes’ prize … because none of the judges believed that anyone but Nègre himself could produce such beautiful photo-engraved plates.’
Luynes died before the work would be published, leaving the task to his son and Le Comte de Vogëé. Perhaps to save expense, they commissioned Eugene Ciceri, who had acquired fame as a lithographist around 1865, to reproduce the Sauvaire photographs lithographically. Without denying his artistic talent, it must be acknowledged that the quality of his results is inferior by far to that obtained by Nègre.
While the archaeological and scientific observations within the text were groundbreaking at the time, the work is today best appreciated for its stunning atlas of photogravure plates. To the small but vitally important field of nineteenth-century photomechanical process, Nègre brought not only technical expertise but also the eye of a master photographer and painter. Quite possibly de Luynes had expected Nègre to win the prize or at least he clearly favored the photogravure print for it’s beauty, permanence and tonal nuance. Voyage d’exploration: la Mer Morte remains one of the finest photo-mechanically printed books of the era.
